🔷Product Drawing
![]()
🔷Basic Performance Spec
Th = 40°C
| Type Model | In APE | Max Temp Diff. ▲Tmax (°C) | Internal Resistance ACRohm (Ω) | Max Voltage Umax (V) | Max Current Imax (A) | Max Power Pmax (W) | Size (mm) |
|---|
| TEC1-09710 | K10 | 60 | 0.94 | 12 | 10 | 120 | 40x40x3.4 |
| K14 | 65 | 0.94 | 12 | 10 | 120 | 40x40x3.8 |
| K18 | 70 | 0.94 | 12 | 10 | 120 | 40x40x4.2 |
🔷Additional Performance Spec
| Parameter | Specification |
|---|
| Substrate Specification | 96% Alumina (Al₂O₃) 0.76 + Oxygen-Free Copper 0.4 sintering process |
| Lead Wire Specification | Special soft silicone wire 18AWG / L=200mm |
| Terminal Specification | Standard products have no terminals; can be added upon request |
| Assembly Pressure | 4kg / (0.25kg/CM²) |
| Packaging Standard | Polystyrene (PS) foam box packaging |
| Sealing Material | 704 silicone rubber seal |
| Max Temperature Resistance | Bismuth-tin (Bi-Sn) environmentally friendly solder, melting point 138°C |
| Storage Environment | Temperature < 120°C, Humidity < 60%Rh |
🔷Performance Curve
![]()
🔷Product Overview
The TEC1-09110 Thermoelectric Cooler 40×40mm is a compact Peltier thermoelectric cooling module designed for applications that require localized cooling and precise temperature control.
Unlike conventional compressor-based cooling systems, a thermoelectric cooler uses the Peltier effect to transfer heat from one side of the module to the other when DC power is applied.
With its 40×40mm compact format, the TEC1-09110 can be integrated into a variety of electronic equipment, instruments, thermal management systems, and temperature-control devices.
As a professional thermoelectric cooler manufacturer, we provide thermoelectric cooling modules for OEM, ODM, wholesale, and bulk purchasing requirements.
For customers looking for a thermoelectric cooler supplier in China, customized module dimensions, electrical specifications, wire configurations, and packaging requirements can also be discussed according to the project.
🔷Product Features
1. Compact 40×40mm Size
The 40×40mm structure allows the TEC1-09110 to be integrated into compact equipment where installation space is limited.
2. Peltier Thermoelectric Cooling
The module uses semiconductor thermoelectric technology to achieve solid-state cooling without mechanical moving parts.
3. Precise Temperature Control
Thermoelectric cooling can be controlled by adjusting the electrical input, making it suitable for applications requiring localized temperature management.
4. Compact Solid-State Structure
The module has no compressor or refrigerant system, allowing it to be integrated into compact electronic and thermal management equipment.
5. OEM & ODM Support
Different wire specifications, module configurations, dimensions, and other requirements can be customized for OEM and ODM projects.
6. Suitable for Bulk Purchasing
As a thermoelectric cooler factory and wholesale supplier, we support bulk orders for equipment manufacturers, distributors, and system integrators.
🔷Product Applications
The TEC1-09110 thermoelectric cooler can be used in equipment requiring compact cooling or localized temperature control.
Typical applications include:
- Laser cooling equipment
- Optical equipment
- Semiconductor equipment
- Electronic equipment cooling
- Precision instruments
- Laboratory equipment
- Medical instruments
- Sensor temperature control
- Camera cooling systems
- Detector temperature control
- Industrial temperature control
- Small cooling systems
- Portable cooling equipment
- Temperature stabilization equipment
For OEM equipment manufacturers, the module can be integrated into customized thermal management systems according to the required cooling capacity and operating conditions.
🔷Product Structure
![]()
🔷Operation Principle / Work Principle
The thermoelectric cooler works based on the Peltier effect.
When DC current passes through the semiconductor elements inside the module, heat is absorbed on one side of the module and released on the opposite side.
Therefore, the module produces:
Cold Side → Heat Absorption → Thermoelectric Elements → Heat Transfer → Hot Side → Heat Dissipation
The cold side can be connected to the target component or cooling object, while the hot side normally needs to be connected to a suitable heat sink or heat dissipation system.
The actual cooling performance depends not only on the thermoelectric cooler itself, but also on the heat dissipation capacity of the hot side.
For this reason, proper matching between the TEC module, heat sink, thermal interface material, power supply, and control system is important when designing a thermoelectric cooling system.
🔷FAQ
Q1: What is the TEC1-09110 thermoelectric cooler?
The TEC1-09110 is a 40×40mm thermoelectric cooler / Peltier module designed for localized cooling and temperature-control applications.
Q2: Is TEC1-09110 suitable for OEM projects?
Yes. The module can be considered for OEM and ODM applications. Wire specifications, configuration, packaging, and other requirements can be discussed according to the project.
Q3: Can I buy TEC1-09110 in bulk?
Yes. Bulk and wholesale purchasing can be supported for equipment manufacturers, distributors, and system integrators.
Q4: Are you a thermoelectric cooler manufacturer?
We provide thermoelectric cooler and Peltier module manufacturing support for OEM, ODM, wholesale, and bulk requirements.
Q5: Can the thermoelectric cooler be customized?
Yes. Custom thermoelectric cooler requirements may include dimensions, wire specifications, wire length, connector type, electrical parameters, and other module configurations.
Q6: How should I select a thermoelectric cooler?
The selection should consider the required cooling capacity, temperature difference, operating voltage, current, hot-side temperature, heat dissipation capability, module size, and installation conditions.
Q7: What is the difference between a thermoelectric cooler and a Peltier module?
In many product applications, thermoelectric cooler, TEC module, and Peltier module are used to describe thermoelectric cooling devices based on the Peltier effect. The exact terminology can vary depending on the application and product configuration.
Q8: Can you provide a thermoelectric cooler supplier service in China?
Yes. For customers looking for a thermoelectric cooler supplier China, manufacturer China, wholesale, OEM, or bulk purchasing solution, product specifications and project requirements can be discussed before production.
